1. DESCRIPTION
   PHOTO+ is a peripheral for IRISTEXT-4000-Pro message generator with I-GLNK option. It allows still video pictures to be associated with IRISTEXT-4000's alpha graphic pages. These pictures issued from a camera, a video tape recorder or any other video source are digitized and stored on magnetic disc.

2. STORAGE CAPACITY
   - 5850 frames full size minimum, potential over 64000 according to size.

3. ACCESS TIME
   - Less than 2 Seconds.

4. RESOLUTION
   - 720 X 486 (CCIR-601 STANDARD) or 540 lines.
   - YUV 4:2:2 (FRAME)
   - quantization: 8-bits lum. 8-bit chroma

5. IRISTEXT INTERFACE
   - Controlled by I-4000-Pro via RS-232 (DB9M connector)
   - picture commands such as:

   selection of still pictures or "live" source
   images capture
   multi-photo editing: zoom, inversion, field 1 or 2 or full frame.
   file maintenance: erase, copy, move.

6. VIDEO INPUT FORMAT
   - 2 composite sources (BNC connector via adapter) or Y/C (NTSC) ( 4 pins mini-din connector) or composite analog source (Y, R-Y, B-Y)
   - integrated time base corrector
   - input filter for unstable sources such as tape recorders

7. BROADCAST QUALITY NTSC OUTPUT (refer to following measurement report)
   - RS-170A
   - GENLOCK on one of the 2 composite inputs or on black burst (BNC connector)

8. PICTURE TRANSITIONS
   - cross fade
   - fade to black
   - fade from black
   - immediate

9. PICTURE FORMAT COMPATIBILITY
   - .TGA (TARGA)
   - .BMP (DEVICE-INDEPENDENT BITMAP)
   - .YUV (4:2:2)

10. LOCAL AREA NETWORK INTERFACE
    - Allows other computers on the network to exchange or update picture and audio files with photo+
    - Allows a central unit with the Photo+ option to update other Photo+ units
    - Automatic file copy to other Photo+ on the network following image or audio capture
    - Ethernet IEEE 802.3 10 base T or 10 base 2
    - TCP/IP, NetBEUI and IPX/SPX protocol support


11. AUDIO OPTION (I-AUDIO-1 or I-AUDIO-2)
    - 1 or 2 channels option allowing to capture sound without interrupting display
    - mono input for dynamic microphone with low impedance or electret
    - auxiliary stereo input
    - stereo output which can directly supply loudspeakers
    - fade between auxiliary input and audio file
    - PCM format ("wave "file)


12. PHOTO+ INDEPENDENT SECOND CHANNEL OPTION (I-PHOTOp)
    - added to I-VIDL-Sr for offline preparation of pictures
    - allows picture independent display of different pictures in the 2 channels (with I-VIDT-Sr)
    - 3., 4., 6., 7., 8. and 9. technical specifications above also apply to this 2nd PHOTO+ channel.


13. FRONT PANEL
    - locking door for access to control buttons
    - access to removable fan filter

    INDICATOR LIGHTS

    - power supply
    - hard disk access


    CONTROL BUTTONS

    - AC power
    - reset



14. POWER
    - 120 VAC nominal (90-132 VAC) or 240 VAC nominal (180-264VAC)
       47 to 63Hz by switch selection
    - 6 Amp. max at 120Vac, 4 Amp. to 240VAC
    - detachable IEC 320 cord


15. DIMENSIONS
    - can be installed in standard 19" rack
    - uses 4 rack space units


    height width width depth depth net weight shipping weight shipping size

    = 7" (17.7cm) = 19" (48.2cm) including 19" rack support = 17.3" (43.9cm) excluding 19" rack support = 19.8" (50.3cm) with front handles = 17.8" (45.2cm) without front handles = 35 lbs. (16kg) = 50 lbs. (23kg) = 26" x 22 " x 14"

Video measurement system: TEKTRONIX VM-700A
Video Source: TSG-130 generator

NTSC MEASUREMENTS Bar Amplitude Sync Amplitude Blanking Variation Sync Variation Burst Amplitude FCC H Blanking FCC Sync Width FCC Sync-setup FCC Front Porch Sync to Burst End Breezeway Width FCC Burst Width Sync Rise time Sync Fall time RS-170A H Blanking RS-170A Sync Width RS-170A Sync-Setup RS-170A Front Porch Sync to Burst Start RS-170A Burst Width V Blank 4 IRE F1 V Blank 4 IRE F2 FCC Equalizer FCC Serration RS-170A Equalizer RS-170A Serration Line Time Distortion Pulse/Bar Ratio 2T Pulse K-Factor IEEE-511 ST Dist S/N Periodic Chroma-Lum Delay Chroma-Lum Gain Differential Gain Differential Phase Lum Non-Linearity Frequency Response @ 4.2 MHz

PHOTO+ 100.5 IRE 43.0% Bar 0.5% Bar 0.2% Bar 40.3% Bar 11.09 us 4.79 us 9.49 us 1.60 us 7.94 us 0.73 us 8.7 Cycles 104. ns 119. ns 12.16 us 4.68 us 9.44 us 1.66 us 5.43 us 9.0 Cycles 21.0 Lines 21.6 Lines 52.4% S.W. 4.58 us 2.40 us 4.69 us 0.2% 101.9% 0.6% Kf 1.4% SD 52.7 dB -7.7 ns 99.3% 0.42% 0.39 Deg 6.26% -0.85 dB

PHOTO+ VIDEO INPUT CABLE




PHOTO+ VIDEO OUTPUT CABLE
